Introduction:
Our company was established in year 2009 we have completed various projects with many reputed companies which include custom project fabrication.
We have team of qualified technical personals. Who have helped us to carve a niche for ourselves in the field. We have a view to fill up the void created by a crisis of contractors with professionals who would support the clients in their infrastructural and turnkey projects in a better way. Our team members have an in-depth knowledge of the matter and put their heart and soul into the projects to deliver the best service. Many of clients being satisfied with our Work.
About Us
We @ PRRAY FAB INDUSTRIES manufacturers of high quality of Stringing & Erection Tools. We maintain a superior level of integrity in interactions with business partners and associates and we conduct our business as a Model Corporate Citizens.
Our Mission
Our MISSION is to manufacture the improved quality of stringing and erection tools utilizing quality practice and latest technology involvement, we also wish to produce and invent the new tools may be suitable for some activities during Stringing and Erection activity.
Our Vision
Our VISION is to continuously work towards improving our Processes of manufacturing, Products and after sale services that not only satisfy the Customer’s Needs but also surpasses the Customers Expectations of Quality, Safety and Reliability.
Our Team
Our TEAM comprises of Senior Engineers, Mechanical Engineers from Transmission Lines Industry who are well knowledgeable in Machine Operating.
We have a strong R & D Team that includes trained engineers and people who have more than 10 years of experience in the Transmission Lines industry. These people are capable of producing not only world class products but are also technically sound to create special solutions for engineering needs of the T&D Industry.
We have testing facilities at our plants that is equipped with various testing machines like load testing, material testing machines etc.
We Manufacture
- Single sheave pulley
- Double sheave pulley
- Four sheave pulley
- Equalizer pulley
- Drum jack
- Turn buckle
- Automatic clamp
- Come along clamp
- Aerial roller
- Pilot wire drum
- Compressor joint machine
- Double caption winch machine
- Hydraulic winch machine
- Hydraulic conductor cutter
- All type of stringing tools accessories
- Many other products also
Company Details
| Details | Information |
|---|---|
| Name Of Organization | PRRAY FAB INDUSTRIES |
| Type of Supplier | Manufacturer |
| Year Of Establishment | 2017 |
Office Address
B – 1, SHREE HARI ARCADE,
VILLAGE : BAKROL BUJRANG,
TA. DASKOI,
Ahmedabad – 382430
Unit – 1
B – 1, SHREE HARI ARCADE,
VILLAGE : BAKROL BUJRANG,
TA. DASKOI,
AHMEDABAD – 382430
Factory Area
- UNIT – 1 : TOTAL PLOT AREA – 1400 SQ. YARD
- UNIT – 2 : TOTAL PLOT AREA – 520 SQ. YARD
Range of Products
- Storage tank – capacity up to 85,000 ltrs
- Storage tank – Capacity 5 mtrs Dia.
- All type of stringing tools for TNP Line
- Specialist SPM machine
- Precision job work
Production Capacity
700 Tons Per Year
Details of Employees
| Category | Quantity |
|---|---|
| Total Number of Employees | 41 Person |
| Engineer / Supervisor | 09 |
| Turner | 03 |
| Fitter | 04 |
| Qualified Arc / MIG Welder | 04 |
| Qualified TIG Welder | 02 |
| Casual Welder | 03 |
| Drawing Fitter | 05 |
| Riggers | 05 |
| Casual Workers | 06 |
Services
- Equipment Fabrication like Transformer tanks like 5 MVA to 60 MVA, Heat Exchanger, Pressure vessels, tanks & other Engineering Applications.
- Core channel of transformer fabrication.
- Shot Blasting & Painting.
- Hot Dip Galvanizing & Galvanizing Work for Structural & other Engineering Applications.
- Operation & Maintenance contracts of various types of industries.
Machinery Description
- Laser Cutting Machine 3000W – 01 No.
- Over Head Crane With Electrically Operated Hoist 5 Tons Capacity – 01 No.
- MIG Machine 400 Amp – 04 Nos.
- ARC + TIG Machine 400 Amp – 02 Nos.
- Arc Machine 400 Amp – 02 Nos.
- Arc Machine 200 Amp – 02 Nos.
- Pillar Drill 42 MM Dia Capacity – 01 No.
- Magnet Drill 31 MM Dia Capacity – 01 No.
- Tools & Tackles Set – 01 No.
- Hand Cutter 14” – 04 No.
- Hand Grinder 4” – 10 No.
- Hand Grinder 7” – 03 No.
- Chain Block Pulley 5 Ton with 30 Ft Height Working Capacity – 04 No.
- Gas Cutting Set with Cutting Torch & 15 Mtrs Long Hose – 03 No.
- PUG Cutting Set – 02 Nos.
- Compressor 500 Ltrs with Painting Gun – 04 No.
- CNC Bending Machine
- CNC Turning Center – 3 Nos.
- VMC Machine – 2 Nos.
- Bandsaw Machine – 1 No.
Clients
- KALPTARU POWER TRANSMISSION
- ADVAIT INFRATECH Pvt. Ltd
- POWERLITE, NARODA, AHMEDABAD
- TATA PROJECT LIMITED (TPL)
- WADIA BODY BUILDERS
- TATA PROJECTS LTD.
- MAMTA MACHINERY MFG.CO PVT
- GABBAR ENGINEERING CO.
- GINZA MACHINERY CO.
- CAREFOAM INDUSTRIES
- ATS LIMITED
Products & Technical Details
Motorized Compressor Machine
Technical Details
- Equipped with quick release couplings
- Engine : Four stroke petrol engine Honda GX200, 5.5 HP
- Flow : 1.4 L/Min
- Max Oil Pressure : 700 bar
- Oil Tank Capacity : 20 Lt.
- Weight : 69 Kg
- Size : 63 × 48 × 50 cm
Hydraulic Press of 100 Ton, 125 Ton, 150 Ton Compressive Capacity for compression of Joints on Conductor and Steel Rope for High Voltage Electric Line.
Manual Drum Lifting Jack
Technical Details
- Suitable for paying out cables during stringing conductor operations
- Reel lifting by manual jack hand operated gear mechanism
- Completely detachable frame for easy transportation
- Mechanical disk braking system to control the drum while unwinding conductor
Turn Table
Technical Details
- Made of Mild Steel
- Suitable for Reel Dia. 1800 – 2400 mm
- With braking arrangement
- Weight : 185 Kg
- Available in 3 Ton & 8 Ton for Earth Wire
Single Sheave Close Pulley
Technical Details
- Frame made of MS and painted
- Suitable for steel rope
- Wheels mounted on ball bearings
- Sheave Diameter : 150 mm
- SWL : 10 Ton
- Weight : 11 Kg
Two Sheave Pulley
Technical Details
- Frame made of MS and painted
- Suitable for steel rope
- Wheels mounted on ball bearings
- Sheave Diameter : 150 mm
- SWL : 5 Ton
- Weight : 14 Kg
Four Sheave Pulley
Technical Details
- Heavy design for better protection of sheave
- Suitable for steel rope
- Wheels mounted on ball bearings
- SWL : 10 Ton
- Weight : 23 Kg
Six Sheave Pulley
Technical Details
- Heavy design for better protection of sheave
- Suitable for steel rope
- Wheels mounted on ball bearings
- SWL : 10 Ton
- Weight : 28 Kg
Turn Buckle
Technical Details
- Used to anchor/tight various accessories, conductor and equipment during stringing operation
- Made of galvanized steel
- Available in dual hook, dual eye and eye-hook configuration
- SWL : Available in 5 Ton & 10 Ton
- Weight : 9 Kg & 16 Kg
Joint Protector For Conductor
Technical Details
- Made of heavy-duty steel tube
- Both side rubber brushes to avoid damage of conductor
- Specifically designed to protect the mid span
- Joint made at tensioner station
Three Bolt Come Along Clamp / Seven Bolt Come Along Clamp
Technical Details
- Body made of steel in two parts
- Alloy aluminum liners provided to grip conductor
- Hook and eye bolts made of carbon steel
- SWL : 2 Ton / 10 Ton
- Weight : 11 / 17 Kg
Single / Double End Sock Joint For Conductor
The Head type temporary mesh sock joints are specifically designed to temporarily connect the aluminum, steel or copper conductor to the pulling rope.
They consist of variable pitch steel wires, which effectively distribute the gripping effect on the conductor.
Kitto Clamp
Technical Details
- Material : Mild Steel
- Pin : EN8
- Suitable for 8mm to 12mm wire rope
- Coating : Epoxy primer and enamel paint
- Weight : 3.5 Kg
Patta Clamp For Earth Wire
Technical Details
- Available for different earth wire
- Frame made of mild steel
- Rust protection with primer and enamel paint
- Safe Working Load : 5 Ton
Equalizer Pulley
Technical Details
- Material : Mild Steel
- OD : 300mm
- Groove Width : 28mm
- Groove Depth : 30mm
- SWL : 10 Ton
- Weight : 18 Kg
- Shaft : EN-8 Steel 36mm Dia
- Bush Material : Gun Metal
- Hooks : EN-8 Forged Material
- Rust protection with primer and enamel paint
Used for pole erection, line construction work, hoist devices etc.
Single Sheave Aerial Roller 300mm / 400mm
Technical Details
- Frame : Mild Steel
- Motion : Ball Bearing
- Coating : Epoxy primer and enamel painted
- Sheave Dimension : 300 × 236 × 65mm
- Safe Working Load : 2.5 Ton
- Weight : 10 Kg
Manual Sag Winch
Technical Details
- Body made of steel
- Helical gears duly tempered
- Rotated on thrust bearings
- Pulley suitable for 8–12 mm rope
- 2 speed arrangement
- Extra accessories for tower fixing provided
- Working Load : 10 Ton
Swivel or Articulated Joint
Technical Details
- Material : High tensile steel
- Heat treatment : Furnace heated, oil quenched and tempered
- Coating : Zinc
- SWL : 1.6 Ton / 5 Ton / 10 Ton / 25 Ton Available
S Type Roller
Technical Details
- Frame : Mild Steel
- Motion : Ball Bearing
- Coating : Epoxy primer and enamel painted
- Sheave Dimension : 300 × 236 × 65mm
- Safe Working Load : 2.5 Ton
- Weight : 10 Kg
The rollers are made of aluminum alloy and grooves are lined with neoprene rubber flap.
Hanging Pulley
Cable replacers are used wherever existing GW is required to replace by OPGW.
The frame is fabricated from alloy steel while the rollers are made of nylon.
Tandom Type Roller
These rollers are used during stringing of single conductor, OPGW and sometimes used as marking roller.
The frames are made of alloy steel while rollers are made of nylon.
Automatic Clamp For Conductor
Technical Details
- Maximum safety load : 5 Ton
- Weight : 16 Kg
- No slipping of wire for highest pulling forces
The design of the clamp is simple and operation is easy with positive grip on conductor.
Ground Roller
The barrels are made of rubber molding and roll on ball bearings while the stands are fabricated from alloy steel tubes and flats.
Pilot Wire Connector
Technical Details
- Made of high tensile galvanized steel
- Suitable for connecting two pilot wire lengths together
- Supplied with cover roller / sleeve to avoid sharp bending of pilot eye
Sag Plate
Technical Details
- Body frame made of Mild Steel
- Rust protection with primer and enamel paint
- Safe Working Load : 5 Ton
- Weight : 18 Kg
Cradle Reel Stand For Pilot Wire Reel
The reel stand is made of welded steel pipes and used to support & lift the pilot reel and provide required ground clearance during payout operation.
Supplied with shaft, bracket support and one side brake.
Empty Steel Reel
The reel is made of welded iron sections with protective paint or coating to prevent rusting.
Used to wind and unwind the pilot wire in case of any damage to original reel.
Power Winch Machine
(Title Mentioned in Catalogue)
